Standard: Adapted to VDE 0250 / 0281 / 0282

Nominal Voltage: Uo / U 600 / 1000V. Control cores 250V

Insulation Resistance: Min. 20 GΩ x cm

Temperature Range: Flexing -5°C to +70°C. Fixed installation -30°C to +70°C

Minimum Bending Radius: Flexing 12 x cable ø. Fixed installation 4 x cable ø

Test Voltage: Supply cores: C/C 4000V & C/S: 2000 V

Control cores: C/C: 1500 V, C/S: 750 V
